◆好產品特質 Product features
1. 設計制作大(da)氣(qi),看上(shang)去大(da)方(fang),環保型好用(yong)好;
2. 可以(yi)調節式風暴溶(rong)合(he)(he)器,能將能用研磨(mo)材(cai)料與(yu)細微(wei)灰塵溶(rong)合(he)(he),好的研磨(mo)材(cai)料重新適用;
3. 其主要零元器件按照(zhao)高質量進口配件上的,運行時間長;
4. 生產制作工(gong)件產品面均;
5. 多工序方案;實操員可直接實操噴砂。隨著投資者各種需求,要選擇系統自動或系統自動 ;可按投資者規范要求訂作!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆符合使用范圍 Applicable scope
石材(cai),PC電腦殼子(zi),功放音響開關按(an)鈕,漢堡包烤盤(pan)等平(ping)面(mian)磨及(ji)方體鏜孔(kong)的噴(pen)砂制造。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆最主要的技術技術指標 Main technical parameters
|
器機主要參(can)數 Model |
STR-多工位輸送式噴砂機 |
|
機床寬度 Complete machine size(mm) |
3000×1000×1700 |
|
做工作(zuo)空間 Work space(mm) |
2000×1000×800 |
|
外(wai)傳輸長寬高 Conveying the size(mm) |
500×1000×1000(2件) |
|
吸塵箱尺寸大小 Dedust box sizes(mm) |
600×600×1800 |
|
破乳器(qi)電(dian)動機 Separator motor |
220V 50HZ 550W |
|
破乳(ru)器排風量 Separator air volume |
8.5m3/min |
|
收縮(suo)熱(re)空氣(qi)源(yuan) Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W防火燈 |
|
產品總重量 Machine weight |
550kg |
